Scbh15 Amorphous Alloy 11kv 50kva Dry Type Transformer

"SCBH15" is named according to the national standards for transformers. Each letter and number represents a specific technical characteristic. For example, "S" stands for three phase and is applicable to three phase AC power supply systems; "C" represents resin cast type, indicating that the coil is insulated by epoxy resin and belongs to a dry type transformer; "H" represents amorphous alloy core, which is the most core energy saving feature of this model. It uses amorphous alloy materials instead of traditional silicon steel sheets; "15" stands for the performance level code or design sequence, reflecting that the loss level of this series of products complies with relevant standards. The larger the number, the more energy efficient it is.

The scbh15 amorphous alloy 11kv 50kva dry type transformer adopts a three phase five column structure and the core is protected by a frame structure. The product features low temperature rise and strong heat dissipation performance. Under air cooling conditions, it can withstand 150% of the rated load. A complete temperature control protection system is adopted to provide reliable guarantee for the safe operation of the transformer. So the short circuit resistance is very strong.

To provide better protection for the core material and the coil of scbh15 amorphous alloy 11kv 50kva dry type transformer, and to effectively prevent corrosion and detachment, the amorphous alloy core is completely enveloped by the resin and the high temperature resistant silicone gel. In the meanwhile, by adopting special materials to improve the structure of core and coil can greatly reduce the noise during the operation process.

Technical parameter:

Q: For this scbh15 amorphous alloy 11kv 50kva dry type transformer, compared to ordinary silicon steel sheet dry type transformers of the same capacity and voltage level (such as SCB12 or SCB14), how much more is the purchase cost? How long will the saved electricity cost be able to recover the investment?

A: The core advantage of scbh15 amorphous alloy 11kv 50kva dry type transformer is that their no load loss is extremely low (about 70% lower than that of silicon steel sheets). However, the cost of raw materials and manufacturing for these transformers is higher. For transformers with a capacity of 50kVA or less, users are most concerned about the initial cost investment and the payback period of the investment when making a selection.

The purchase price of SCBH15 amorphous alloy 11kv 50kva dry type transformer is usually ¥3,000 to ¥5,000 higher than that of SCB12.The no load loss of your SCBH15 transformer is approximately 90W; while the no load loss of a typical SCB12 silicon steel sheet transformer is about 210W.

By calculating (0.210kW - 0.090kW) × 8760 hours/year ≈ 1051 kWh. Estimating at an industrial electricity price of ¥0.8 per kWh, the annual cost is approximately 840 yuan. Therefore, the investment payback period is about 4 to 6 years. If the scbh15 amorphous alloy 11kv 50kva dry type transformer, operates at a low or no load state for a long time such as at night or during holidays, the payback period will be shorter and the advantages of amorphous alloy will be more obvious; if it operates at full load for a long time, the advantages will be masked by the load loss and the payback period will be longer.
