China Load Break Switch LBS Supplier With Factory Price

What is the purpose of a Load Break Switch LBS?

A Load Break Switch LBS is designed to close or separate to upstream medium voltage power distribution line on service. The indoor type Load Break Switch LBS could have the over load protection and short circuit protection combining with the fuse.

Classified by insulating medium, it has sf6 gas insulated Load Break Switch LBS, vacuum interrupter type load breaker switch, and air insulated Load Break Switch LBS. Classified by installing environment, it is indoor type Load Break Switch LBS, sf6 gas insulated pole mounted type Load Break Switch LBS, overhead air insulated type Load Break Switch LBS.

Indoor Electrical Motorized Load Break Switches

What is the difference between a breaker and a Load Break Switch LBS?

A circuit breaker could automatically and independently shut down electrical circuit on service to protect electrical device from the damage of short circuit and over load. However, a Load Break Switch LBS needs to combine with the fuse to have the function of short circuit protection and overload protection. That is to say, a Load Break Switch LBS only can handle the normal load currents, but a circuit breaker could deal with the both. Fortunately, a indoor type Load Break Switch LBS is integrated with an earthing switch, which make it becomes to an economical power solutions.

View as

Indoor Electrical Motorized Load Break Switches

Wenzhou XiFa Electric Power Equipment Co., Ltd is an experience factory to produce load break switch. To manufacture a solid indoor electrical motorized load break switches, the company uses silver alloy plating on the contact surface to enhance resistance to arc erosion and oxidation. Meanwhile, to achieve a better performance on mechanical strength and partial discharge resistance, the company adopts epoxy resin as the main insulation material. Ever more, to chase operating mechanism closes smoothly, Wenzhou XiFa Electric Power Equipment Co., Ltd will inspect the machining accuracy for each components before assembling and apply lubrication to the operating mechanism.

View More >> Send Inquiry >>

11 Kv Overhead Air Load Break Switch

To Produce a reliable 11 kv overhead air load break switch, Wenzhou XiFa Electric Power Equipment Co., Ltd adopts hot dip galvanized steel as the mounting frame to chasing the ability of outdoor corrosion resistance. Meanwhile, each 11 kv overhead air load break switch use epoxy resin as insulation material on phase to phase to control creepage distance and phase insulation. Additionally, the pole mounted air load break switch adopts Insulated operating rod and electric mechanism to achieve the operation method of manual type and motor driving type respectively to fit the various working environment.

View More >> Send Inquiry >>

Enclosed Pole Mounted Load Break Switch

To produce a high quality enclosed pole mounted load break switch, Wenzhou XiFa Electric Power Equipment Co., Ltd adopts tungsten inert gas welding technology and multi layer sealing structure to produce the enclosure chasing a better performance on airtightness. Meanwhile, Wenzhou XiFa Electric Power Equipment Co., Ltd also focus on the springs and bearings could provide smooth action on each enclosed pole mounted load break switch. The relative test shall be done in the producing process and after enclosed pole mounted load break switch finish to assemble to ensure the better performance on operational resilience.

View More >> Send Inquiry >>

Mv Vacuum Fuse Load Break Switch 11kv

Wenzhou XiFa Electric Power Equipment Co., Ltd is reliable manufacture to produce load breaking switch. The mv vacuum fuse load break switch 11kv has outstanding breaking capacity and dielectric properties, meanwhile, the load breaker switch can effectively match the safe operation requirements of the power distribution system. Ever more, The company adopts vacuum arc extinguishing technology, which has no greenhouse gas emissions. Combining with fuse, the mv vacuum load break switch could be shut down circuit under the overload and over current.

View More >> Send Inquiry >>

Medium Voltage 630a Lbs Load Break Switch

To produce a solid medium voltage 630a lbs load break switch, Wenzhou XiFa Electric Power Equipment Co., Ltd adopts epoxy resin as the insulation material to chasing a better performance on high dielectric strength and aging resistance. Meanwhile, the contact pressure will be tested on producing process of each medium voltage 630a lbs load break switch to ensure the reliable switch closure. Ever more, the factory test will undergo on each medium voltage 630a lbs load break switch to ensure zero defects.

View More >> Send Inquiry >>

11kv Sf6 Gas Load Break Switch Lbs

Wenzhou XiFa Electric Power Equipment Co., Ltd is a professional factory to produce 11kv sf6 gas load break switch lbs. The factory adopts laser welding process and helium leak detection to drop leakage rate to 0.5% per year. Meanwhile, to ensure each 11kv sf6 gas load break switch lbs reach to the target electrical insulation strength, it equips air pressure relay and temperature and humidity controller. Ever more, the 11kv sf6 gas load break switch lbs is modular design to ensure the consistency in the process of assembling.

View More >> Send Inquiry >>

Xifa is a professional Load Break Switch LBS manufacturer and supplier in China. We warmly welcome you to wholesale high quality products at competitive price from our factory.
